1.1. E30 – BMW 3 Series (a 2-door compartment, the 4-door sedan), 1983-91 of release

GENERAL INFORMATION

BMW 3 Series

Engine 1,6 liters

Engine 2,0 liters

The body of E30 replaced the previous body of E21 of the small third BMW series which became popular in 1983. First E30 was more modifed E21, than absolutely new car and used generally the same engines. The main constructive changes concerned forward and back suspension brackets and ergonomics of salon. However designers of firm so well worked over appearance that magnificent proportions of E30 still admire admirers of BMW, and style of this car began to be considered as classical. On the other hand, since E30 the firm refused the front grille mown forward which was characteristic feature of all cars of BMW for the previous 20 years. It caused some resonance in the ranks of adherents of BMW style. E30 body got something, but something lost BMW.

Modifications the versatile person and кабрио continued to be issued till 1993, but generally production E30 was stopped in 1991 as a result of change of a body of the 3rd series with E36.
Wheel base: 2565 mm
Track (forward/back):
1412 / 1424 mm
Length:
4345 mm
Width:
1680 mm
Height:
1370 mm

E30 for the first time appeared in January, 1983 in the only option of a 2-door compartment. Only in a year, in January, 1984 buyers had a choice opportunity with the advent of the 4-door sedan that at once strongly increased popularity of model. In 1986 E30 cabriolet went on sale. And it is only close to the end of production E30 Bavarians pleased with the versatile person. However, luggage compartment could not brag of considerable volume, but the car just perfectly looked. Other rare modification – model 325iX with the four-wheel drive – borrowed transmission from all-wheel drive "five" in E34 body. Also diesel modifications of the sedan were issued.

Of course, most remarkable car in the 30th body is M3 of office Motorsport for participation in the races FIA GT. This model underwent a set of modifications and had 3 evolutionary versions to conform to the changing requirements of FIA. At the same time M3 was also on broad sale. The model was fantastically successful, constantly held the top places of tables. Paying tribute to fine qualities of E30, it is worth noticing nevertheless that for M3 Motorsport it was forced to make a special suspension bracket, on a design similar to the fifth series (E28 body).

In the middle of 1987 the body underwent easy cosmetic changes. The front grille was slightly lowered, chromeplated a bumper were replaced more fashionable black (and subsequently and painted in color of the car), size of back lamps increased. Practically all cars after 1987 have the power steering (an exception – 318 with the carburetor) and much softer pedal of an accelerator.

The specific mention is deserved by the model 325iS which was issued in 1989-90. On it the new "pyateroshny" six-cylinder M50 engine with a volume of 2.5 liters, 24 192 h.p. klapanamiya is installed. The car was completed with special plastic spoilers, bumpers and thresholds, suspension bracket from M3 and sports salon.

In only 9 years of production more than 2.2 million E30 were produced.

First the younger E30 models used the old four-cylinder M10 engine put for 2002 and E21. Then M10 was laid off and replaced in 1987 with M40 with a new injector and bigger power. But emergence in 1989 to modification of M40 with the M42 code became a real miracle. This engine with two cam-shafts and 24 valves could compete on power to big M30 engines, squeezing out 140 h.p. from the same 1800 cubes and having dynamism of M42 unprecedented before held on in production even till 1996.

The majority of the senior E30 models (320i, 323i, 325i) used the remarkable six-cylinder M20 engine, sharing it with "five" of the same years. Including also the economic model 325e with low-reverse 2.7-liter of M20/B27eta was issued (only in the USA). However on late 325iS new M50 with 24 valves appeared. The rare South African model 333i used the M30 "big six" engine from 5/6/7 series. Also cars with the diesel M21 engine (6 cylinders, 2.4 liters) with a turbo-supercharging were issued and without.

Disk back brakes were put only on 318iS, all 325 models and on M3. ABS standardly was established only on 325e, 325iS and on M3. Optionally was present at late releases of models 320i, 325i and 333i. Some senior models (325, M3) are equipped with the traction control system (differential with limited slipping) with coefficient of 25 of %. For check: number of such differential comes to an end with the letter 'Z'.
Model
Years
sales
Engine System
food
315
83 M10 Solex carburetor
316
83–85 M10 Solex carburetor
316
87–91 M43 Pierburg carburetor
316i
89–91 M43 L-Jetronic
318i
84–86 M10 K-Jetronic
318i
87–91 M40 M1.3
318iS
89–91 M42 M1.7
320i
83–91 M20 L-Jetronic/M1.1
323i
83–86 M20 L-Jetronic
324d
85–86 M21 Diesel
324td
83–91 M21 Turbo Diesel
325e
84–87 M20eta M1.0-Basic
325i (X)
87–91 M20 M1.1/M1.3
325iS
89–91 M50 M1.3
333i
? M30B32 M1.0-Basic
M3
85–93 S14 M1.0///M

Model Weight (kg) Power relation to the weight (hp/t) Time of dispersal 0 – 100 Max. speed (km/h)
315 1100 68 ? ?
316 1100 82 12,4 175
316 1100 ? ? ?
316i 1100 93 ? ?
318i 1100 95 11,2 184
318i 1100 105 10,0 192
318iS 1120 125 9,0 198
320i 1150 109 – 112 10,4 196
323i 1180 121 9,0 204
324d 1150 75 ? ?
324td 1150 100 ? ?
325e 1240 101 ? ?
325i (X) 1200 142 7,9 205
325iS 1200 160 6,7 208
333i 1265 158 ? ?
M3 1260 159 – 189 5,5 223
